SPEC
-
SPECS
- neck type
- ATZ S-TECH WOOD 1pc Roasted Maple neck
- top/back/body
- Alder body
- fretboard
- S-TECH WOOD Roasted Maple fretboardBlack dot inlay
- fret
- Jumbo Stainless Steel fretsPrestige fret edge treatment
- number of frets
- 22
- bridge
- Wilkinson®-Gotoh® VSVG tremolo bridge
- string space
- 10.8mm
- neck pickup
- DiMarzio® The Cruiser® (H) neck pickupPassive/Ceramic
- middle pickup
- DiMarzio® The Cruiser® (H) middle pickupPassive/Ceramic
- bridge pickup
- DiMarzio® The Cruiser® (H) bridge pickup
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D’Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- nut
- Bone
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5″
- a : Width
- 40.5mm at NUT
- b : Width
- 56mm at 21F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 23mm at 12F
- Radius :
- 305mmR
-
DESCRIPTION
-
-
SWITCHING SYSTEM
DESCRIPTION
-
CONTROLS
DESCRIPTION
-
OTHER FEATURES
- Gotoh ® Magnum Lock machine heads w/H.A.P.
- Hardshell case included
Features
Wilkinson®-Gotoh® VSVG tremolo bridge
The Wilkinson®-Gotoh® VSVG tremolo unit features smooth arm action and the unique design of its elongated baseplate screw holes help promote accurate pitch return by eliminating binding. Its locking bent-steel saddles provide a vintage tone and feel.
Smooth taper volume filter
A smooth taper volume filter maintains the guitar’s high frequencies at low volumes and provides more uniform tone from 1 to 10.
DiMarzio® The Cruiser® Pickups
The combination of DiMarzio® The Cruiser® pickups deliver single-coil tone, open vocal-sounding mids and a bit of added strength to the bass. These pickups also relieve players of string drop-outs and sustain-killing magnet pull.
Oil-impregnated Bone nut /Stainless Steel Frets
The Oil-impregnated bone nut provides superior tuning stability and warm rich resonance. Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response, good articulation when playing chords and clear tone when playing single notes.
S-TECH WOOD Roasted Maple fretboard w/Black dot inlay
S-TECH special roasted treatment provides a superior attack and a well-balanced tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.
Gotoh® Magnum Lock machine heads w/H.A.P.(Height Adjustable Post)
The AZ comes with GOTOH® MAGNUM LOCK® machine heads, which have an established reputation for tuning stability. Its H. A. P® (Height Adjustable Post). system allows for the adjustment of string posts for the appropriate tension of each string.
